HPE Aruba Instant On AP25 4×4 Wi‑Fi 6 RW1 Indoor Access Point with Mounting Kit, S0G24A


The HPE Aruba Instant On AP25 4×4 Wi-Fi 6 RW1 (S0G24A) delivers up to 5.3 Gbps for high-density SMBs. With Smart Mesh, 2.5 GbE uplink, WPA3 security, and app-based management, it supports 100+ devices with easy setup and a mounting kit included.

30,000.00 32,000.00

Compare

The HPE Aruba Instant On AP25 4×4 Wi-Fi 6 RW1 Indoor Access Point with Mounting Kit (S0G24A) is a high-performance, business-grade Wi-Fi 6 (802.11ax) access point designed for small and growing businesses, such as tech startups, boutique hotels, gaming environments, and professional offices. Delivering an aggregate peak data rate of 5.3 Gbps (4.8 Gbps on 5 GHz, 574 Mbps on 2.4 GHz), it supports up to 100+ simultaneous devices in high-density environments. Advanced Wi-Fi 6 features, including Orthogonal Frequency-Division Multiple Access (OFDMA), 4×4 Multi-User MIMO (MU-MIMO), and Target Wake Time (TWT), ensure superior speed, efficiency, and reduced latency while extending device battery life. Smart Mesh technology enables wireless network expansion, and a 2.5 GbE uplink port maximizes throughput. Easy to manage via the Aruba Instant On mobile app or cloud-based web portal with no subscription fees, it offers robust security with WPA2/WPA3, Enhanced Open, Two-Factor Authentication (2FA), and up to eight SSIDs. The included mounting kit supports wall, ceiling, or rail installation, and its sleek design blends into any indoor setting. Powered via PoE (802.3at) or a 12V DC adapter (not included), the AP25 is backed by a 2-year warranty.

Technical Specification

  • Wireless Standard: Wi-Fi 6 (802.11ax), backward compatible with 802.11a/b/g/n/ac

  • Radios: Dual-band 2.4 GHz and 5 GHz

  • Data Rates: 4.8 Gbps (5 GHz, 4×4:4), 574 Mbps (2.4 GHz, 4×4:4), 5.3 Gbps total

  • Antennas: Dual omni-directional 4×4 MU-MIMO; Gain: 3.7 dBi (2.4 GHz), 4.5 dBi (5 GHz)

  • Client Capacity: Up to 100+ simultaneous devices

  • Ports: 1 x 2.5 GbE Base-T uplink (PoE-in, 802.3at Class 4)

  • Power: 802.3at PoE (20.1W max) or 12V DC adapter (not included)

  • Management: Aruba Instant On mobile app, web portal, cloud-based, no subscription

  • Security: WPA2, WPA3, Enhanced Open, 2FA, guest portal, up to 8 SSIDs, VLAN tagging

  • Features: OFDMA, 4×4 MU-MIMO, TWT, Smart Mesh, 160 MHz channel (HE160), integrated BLE

  • Mounting: Wall, ceiling, rail (mounting kit included)

  • Dimensions: 20.3 cm (W) x 20.3 cm (D) x 5.1 cm (H)

  • Weight: 1.18 kg

  • Power Consumption: Max 20.1W

  • Certifications: Wi-Fi Alliance Certified 802.11ax (Wi-Fi 6), WPA2, WPA3

  • Warranty: 2 years
