Juniper AP24 Wi-Fi 6E Access Point
The Juniper AP24 Wi-Fi 6E Access Point delivers fast, reliable tri-band connectivity with Mist AI.
Juniper AP24 Access Point – Enterprise-Grade, AI-Driven Wi-Fi 6E Solution
The Juniper AP24 Access Point is a cutting-edge, tri-band Wi-Fi 6E solution designed to deliver fast, reliable, and scalable wireless connectivity for modern enterprises. Powered by the Juniper Mist Cloud Architecture, this entry-level access point leverages AI-driven automation to optimize network performance, reduce operational costs, and enhance user experiences.
Key Features and Technical Specifications
Tri-Band Wi-Fi 6E Performance
-
Supports 802.11ax (Wi-Fi 6E) across 2.4 GHz, 5 GHz, and 6 GHz bands
-
Maximum data rates:
-
2400 Mbps on 6 GHz
-
1200 Mbps on 5 GHz
-
575 Mbps on 2.4 GHz
-
-
Dual-band concurrent design with two spatial streams
-
Ideal for moderate-density enterprise environments
AI-Driven Network Optimization
-
Integrated Mist AI for automated management
-
Radio Resource Management (RRM) dynamically adjusts channel and power settings
-
Dedicated third radio acts as:
-
Network sensor
-
Location sensor
-
Security sensor
-
Enhanced Efficiency and Device Support
-
Supports:
-
OFDMA
-
MU-MIMO
-
BSS Coloring
-
-
Increases spectral efficiency for bandwidth-hungry apps and IoT devices
Cloud-Managed Simplicity and Real-Time Insights
Effortless Deployment and Management
-
Automatically connects to the Juniper Mist Cloud
-
Zero-touch provisioning with automatic configuration and firmware updates
-
Dynamic packet capture for remote troubleshooting
Advanced Analytics with Mist PACE
-
Proactive Analytics and Correlation Engine (PACE) monitors:
-
Service-Level Expectations (SLEs)
-
Network performance
-
Actionable insights for proactive issue resolution
-
IoT and Connectivity Enhancements
Built-In BLE and Energy Efficiency
-
Bluetooth 5.3 with omnidirectional BLE antenna
-
Target Wake Time (TWT) conserves IoT battery life
-
Robust and scalable connectivity for smart devices
Compact, Flexible Design for Indoor Use
-
Dimensions: 185 mm x 185 mm x 39 mm
-
Flexible mounting with universal brackets
-
Ideal for indoor environments with moderate device density
Enterprise Benefits and Sustainability
Cloud Services and Scalability
-
Supports:
-
Juniper Mist Wi-Fi Assurance
-
Marvis Virtual Network Assistant
-
Asset Visibility
-
-
Provides deep visibility into:
-
Network performance
-
User behavior
-
Traffic patterns
-
Eco-Friendly and Future-Proof
-
Ships in eco-conscious packaging
-
Backed by a limited lifetime warranty
-
A future-ready solution for sustainable IT deployments
Why Choose the Juniper AP24?
Whether you’re upgrading an existing network or building a new one, the Juniper AP24 offers:
-
Enterprise-grade performance
-
Simplified, cloud-based management
-
AI-driven insights and automation
-
Cost-effective scalability
Discover how this Wi-Fi 6E access point can transform your wireless infrastructure at juniper.net.
Technical Specifications for Juniper AP24 Access Point
- Wi-Fi Standard:
- 802.11ax (Wi-Fi 6E) with support for 2.4 GHz, 5 GHz, and 6 GHz bands
- Backward compatibility with 802.11a/b/g/n/ac
- Radio Configuration:
- Tri-band capable, dual-band concurrent, tri-radio 2×2:2 802.11ax
- Two client-serving radios (2.4 GHz/5 GHz or 5 GHz/6 GHz)
- Dedicated third tri-band radio for scanning, spectrum analysis, and location analytics
- Maximum Data Rates:
- 6 GHz: 2400 Mbps
- 5 GHz: 1200 Mbps
- 2.4 GHz: 575 Mbps
- MIMO Operation:
- Two spatial stream SU-MIMO for up to 2400 Mbps wireless data rate
- Two spatial stream MU-MIMO for up to 2400 Mbps to up to two MU-MIMO capable devices
- Antenna Options:
- Internal antennas only
- Two 2.4 GHz omnidirectional antennas with 4 dBi peak gain
- Two 5 GHz omnidirectional antennas with 6 dBi peak gain
- Two 6 GHz omnidirectional antennas with 6 dBi peak gain
- IoT Sensors:
- Temperature
- Accelerometer
- IoT Radio:
- Multi-personality with Bluetooth 5.3 and omnidirectional BLE antenna
- Supports IoT electronic shelf label (ESL) tags
- Power Options:
- 802.3af PoE: Full functionality with tri-band operation (2.4 GHz/5 GHz + 1×1 scan or 5 GHz/6 GHz + 1×1 scan)
- I/O Ports and Indicators:
- Eth0: 100/1000/2500 Base-T (802.3bz); RJ45; PoE PD
- USB: USB 2.0 support interface, 900 mA output
- Reset: Reset button to restore factory default settings
- Indicators: One multicolor status LED
- Mounting Options:
- APBR-U universal bracket (included)
- Additional brackets: APBR-ADP-M16 (16mm threaded rod), APBR-ADP-T58 (3/8” threaded rod), APBR-ADP-CR9 (9/16” T-Rail), APBR-ADP-RT15 (15/16” T-Rail), APBR-ADP-WS15 (1-1/2” T-Rail), APBR-ADP-T12 (1/2” threaded rod)
- Dimensions:
- 185 mm x 185 mm x 39 mm
- Weight:
- 0.75 kg
- Shipping Box:
- 244 mm x 227 mm x 64 mm
- Operating Conditions:
- Temperature: 0° to 40°C (internal antenna)
- Humidity: 10% to 90% maximum relative humidity, non-condensing
- Altitude: Up to 3,048 m (10,000 ft)
- Security Features:
- Trusted Platform Module (TPM) for infrastructure security
- Supports WIDS/WIPS via dedicated third radio
- Warranty:
- Limited Lifetime
- Regulatory Compliance:
- Indoor use only for 5.15 GHz–5.35 GHz band
- Compliance with electrical and environmental regulations specific to regions
- Ordering Information:
- AP24-US (United States)
- AP24-WW (Worldwide)
- Additional Features:
- Supports OFDMA, 1024-QAM, MU-MIMO, Target Wake Time (TWT), and BSS Coloring
- AI-driven Radio Resource Management (RRM) for dynamic channel and power assignment
- Proactive Analytics and Correlation Engine (PACE) with machine learning
- Dynamic packet capture and debugging via Juniper Mist platform
- Marvis Virtual Network Assistant for NLP-based troubleshooting
- Transmit Beamforming and Maximal Ratio Combining
